Model：RC4060
Control system：Taiwan Syntec
Spindle：BT40 Pneumatic tools changer
Spindle speed：100-12000RPM
Guide rails：Taiwan linear orbit( Y axis dual)
Rack-pinion：High accurate 2M helical
Motor：Japanese Yaskawa servo, Z with break
Reducer：Japanese Shimpo
| Specification |
| Parameters |
|
|
| Model |
| RC4060 |
| Working size | X axis | 4000mm |
| Y axis | 6000mm |
| Z axis | 1100mm |
| Control system |
| Taiwan Syntec |
| Spindle |
| BT40 Pneumatic tools changer |
| Spindle speed |
| 100-12000RPM |
| Guide rails |
| Taiwan linear orbit( Y axis dual) |
| Rack-pinion |
| High accurate 2M helical |
| Motor |
| Japanese Yaskawa servo, Z with break |
| Reducer |
| Japanese Shimpo |
Applications ：
Military project molds, Wind power molds, Automative molds,Aerospace molds,Vesel molds,Aerospace molds and other large foam and wooden mold machining.
Performance ：
◆ Reinforced square metal tube welded, after annealing and shot blasting treatment,with NC five surface milling,increase machine working stablity.
◆ Whole machine adopts with imported configuration, high accuracy fast speed.
◆ Split machine bed, convenient for transportation.
◆ Machine size and specification available for customization.
◆ Famous brand BT40 spindle, one time milling could remove the nails within wooden foam, high efficiency.
◆ Optional universal angle head,fast milling all the sides except for bottom.Espically suitable for large machine tools,vesel's wooden mold,lost foam casting production.
