| Specification |
| Parameters |
|
| Model |
| RC1530/1525 |
| Working size | X axis | 1500mm |
| Y axis | 2500mm-3000mm |
| Z axis | 350mm |
| Structure | Table | Industrial profiles |
| X、Y、Z | X Y rack-pinion, Z axis ball screw |
| Speed | Travelling speed | 15000mm/min |
| Working speed | 10000mm/min |
| Spindle power | Air cooling 6KW |
| Spindle | Spindle speed | 18000-24000rpm |
| Spindle bore size | ￠20mm |
| Loading size | 400mm |
| Driver |
| Rongchi |
| Voltage |
| AC380V/50Hz |
| Command |
| G-code |
| Control system |
| Rongchi |
Application ：
Sieve plate wear resistant holes milling,carve surface milling,irregular shape lost foam processing.
Performance ：
◆ Easy to operate, save label force, fast speed, high accuracy.
◆ Suitable for mining wear-resistant parts holes drilling, replace 3-5 human being work.
◆ One individual could supervise multiple machine, no need engrave templates,import drawing to process,2D image available for sieve plates.
◆ Whole machine choose heavy duty body structure,annealing treatment,5 sides CNC processing center milling.
◆ Rongchi customized control system,support expand into 5 axis.
◆ Supply with specialized clamps, no concern of workpiece fixing.
